Description:

Controls
CPAP
  • 4 – 20 cmH20 (passive leak port circuits)
IPAP
  • 50 cm H₂O
EPAP/PEEP (a)
  • 0 – 25 cmH20 (active valve circuits)
EPAP/PEEP (b)
  • 4 – 25 cmH20 (passive leak port circuits)
Pressure support
  • 0 – 30 cmH2O
Tidal volume
  • 50 – 2000 ml
Breath rate(a)
  • 0 – 60 BPM (AC mode) BPM
Breath rate(b)
  • 1 – 60 BPM (all other modes) BPM
Inspiratory time
  • 0.3 – 5.0 s Synchrony features
Rise time
  • 1 – 6 (relative scale)
Ramp start pressure (a)
  • 0 – 25 cmH20 (active circuits)
Ramp start pressure (b)
  • 4 – 25 cmH20 (passive circuits)
Ramp start pressure (c)
  • 4 – 19 cmH20 (CPAP mode)
Ramp time
  • Off, 5 – 45 minute(s)
C-Flex
  • Off, 1 – 3 (relative scale)
Flow trigger sensitivity
  • 1 – 9 l/min
Flow cycle sensitivity
  • 10 – 90 %
Environmental
Operating temperature
  • 5 – 40 °C
Relative humidity
  • 15 – 95 %
Storage temperature
  • -20 – 60 °C
Atmospheric pressure
  • 60 – 110 kPa (450 – 825 mmHg)
