The ConMed Beamer CE200 Endoscopic Electrosurgical Unit (#CE200) includes clear display, intuitive rotary controls, and 99 available storage positions for user-defined programs.
Warranty: 2 Years – Extended Warranty available (please see literature tab for Extended Warranty Program).
The ConMed Beamer CE200 Endoscopic Electrosurgical Unit is an electrosurgical generator which offers multiple endoscopic therapies in a single platform. It is the electrosurgeon’s ultimate power tool, enabling practitioners to quickly and intuitively select and deliver multiple therapies at a consistently superior quality.
ConMed Beamer CE200 Endoscopic Electrosurgical Unit Features
- Backlit Rotary Controls: Allow for intuitive, comfortable navigation of the menu and machine parameters with dial controls.
- Automatic Cutting Effect (ACE) provides continuous monitoring of sparks around the active electrode and automatically adjusts voltage, spark, and power.
- Allows five preset modes for varying electrosurgical needs:
- Polyp Cut I: Pulsed cut with minimal coagulation.
- Polyp Cut II: Pulsed cut with strong coagulation.
- Papilla Cut I: Pulse cut with no extra coagulation.
- Papilla Cut II: Pulse cut with minimal coagulation.
- ESD: Pulse cut for submucosal dissection.
- Pre-set speeds provide optimal clinical results.
- Large memory allows 99 storage positions for user-defined programs in addition to the standard preset modes.
ConMed Beamer CE200 Endoscopic Electrosurgical Unit Specifications
- Power Requirements: 100 – 240 V +/- 10% / max. 6.3 A / 6.3 A.
- Nominal Frequencies: 50 / 60 Hz.
- Power Input in Standby Mode: 40 VA.
- Max. Power Input: 600 VA.
- Output Data: Cutting Power (Pulse): Max. 350 watts.
- Output Data: Coagulation Power: Max. 120 watts.
- Output Data: HF Frequencies: 350 – 850 kHz.
- Weight: 18.3 lb (8.3 kg).
- Dimensions: 7.2” x 15.4” x 17.1” (182 mm x 390 mm x 435 mm).
- Shipping Weight: 30 lb (13.5 kg).
- Classification acc. To MDD: llb.
- Type of Applied Part: CF; defibrillation-proof.
- Approval/Mark of Conformity: CE 0297, in compliance with 93 / 42 / EEC.
- LF Leakage Currents: Complying to IEC 601, Part 1 (test in connection with Beamer System.
- Duty Type: INT 10 s (= duty factor of 25%).
